| Rated Load(klb) |
1. 2, 3, 5, 10, 20 |
| Precision C1Insulation Resistance(MΩ) |
≥5000(VDC) |
| Comprehensive Error(%F.S) 0.05Excitation Voltage（V） |
9～12（DC） |
| Rated output(mv/v) 3.0±0.03Compensated temp.Range(℃ ) |
-10～+40 |
| Non-linearity(%F.S) 0.05Use Temp.Range(℃ ) |
-35～+65 |
| Hysteresis(%F.S) 0.05Temp.Effect on Zero(%F.S/10℃) |
0.03 |
| Repeatability(%F.S) 0.03Temp.Effect on Span(%F.S/10℃) |
0.02 |
| Creep(%F.S/30min) 0.02Safe Overload (%F.S) |
150 |
| Zero Balance(%F.S) ±1Ultimate Overload(%F.S) |
200 |
| Input Resistance(Ω) 700±10Defend Grade |
IP67/IP68 |
| Output Resistance(Ω ) 700±10Cable (四芯屏蔽电缆线） |
3~5M |
