额定载荷Rated Load

10t,20t，25t,30t,40t

额定输出Rated Output

2.0000±0.001MV/V

综合误差Total Error

±0.02%F.S

蠕变Creep(30minutes)

±0.02%F.S

推荐工作电压Recommended Excitation Voltage

5V～18V(AC or DC)

最大工作电压Maximum Excitation Voltage

24V(AC or DC)

零点平衡Zero Balance

±1%F.S

输入阻抗Input Impedance

380±5Ω

输出阻抗Output Impedance

350±2Ω

绝缘阻抗Insulation Impedance

≥5000MΩ

安全过载率Safe Overload

150%F.S

极限过载率Ultimate Overload

200%F.S

工作温度范围Operating Temperature Range

(-30～+70)℃

温度补偿范围Compensated Temperature Range

(-20～+60)℃

输出温度影响Temperature Effect On Load

±0.02%F.S/10℃

零点温度影响Temperature Effect On Zero

±0.02%F.S/10℃

材质Construction

合金钢Alloy Steel 铝合金Aluminium

防护等级Protection Class

IP68&IP67

引用标准Citation

GB/T7551-2008/OIML R60

接线方式Mode of Connection

输入+:红 Input+:Red
输入-:黑 Input-:Black
输出+:绿 Output+:Green
输出-:白 Output-:White
